Viscosity & density sensor

Continuous Monitoring of Oil Viscosity, Density and Temperature

VISCOSITY & DENSITY SENSOR
VISCOSITY & DENSITY SENSOR
The VISCOSITY & DENSITY SENSOR is the latest development in oil sensor technology for inline condition monitoring of different application areas: lube and hydraulic oil, fuel quality control, analysis of process media and monitoring of mixing processes. The compact-sized and lightweight sensor enables accurate continuous measurement of three fluid properties: viscosity, mass density and temperature based on a low frequency resonant sensor element.

Technical Features

  • Measuring range:
    Kinematic viscosity: 1 – 400 mm²/s (on request: 1 - 650 mm²/s)
  • Mass density: 0.5 – 1.5 g/cm³
    Temperature: -40°C to +125 °C
  • Accuracy:
    Kinematic viscosity: +/- 1 mm²/s
    Mass density: +/- 0.2 %
    Temperature: +/- 0.1 °C
  • Voltage: 9 - 24 VDC
  • Max. fluid pressure: 50 bar
  • Protection class: IP 67
  • Interface: Modbus RTU (on request: CANopen) /
                    two programmable 4 - 20 mA outputs
  • Fluid compatibility: mineral and synthetic oils (further approvals on request)
The measurement method of the sensor combines an innovative resonator evaluation technology with a robust and reliable quartz crystal tuning fork resonator. Due to the excellent sensing performance, extended viscosity range, high-level accuracy and high measurement rate, the sensor shows outstanding data quality even in unsteady environmental conditions (pressure, temperature, flow, vibration). The screw-mount design of the VISCOSITY & DENSITY SENSOR enables easy integration into existing environments offering digital and configurable analog interfaces. 24/7 inline monitoring of viscosity and/or mass density allows immediate detection of any changes in the fluid condition as well as adequate preventive maintenance actions.
